Surround yourself in the story
Dolby Atmos maps sounds in space for a 3D effect, so you experience planes as if they're flying overhead, hear footsteps moving across the room and feel the score all around you. Fine-tuned by Oscar-winning sound engineers, Arc offers crystal clear dialogue so you can always follow the story. For even greater clarity when characters whisper or the action intensifies, turn on Speech Enhancement in the Sonos app.
.png?v=1673522548764)
Simply beautiful
With only two cables and step-by-step guidance in the Sonos app, Arc is easy to set up, and the elegant design fits seamlessly into your home, whether you place it on furniture or mount it to the wall.
.png?v=1673522610656)
Tuned to perfection
Trueplay tuning technology adapts the sound for the unique acoustics of the room and calibrates the height channels for precise localisation. So your content always sounds just the way it should and reaches your ears at the exact right moment. Get an even more immersive experience with a subwoofer and rear speakers. Everything connects quickly and easily over WiFi so you don’t have to run wires across the room.
Technical Specifications
Included In The Box
Box Contents | Sonos Arc Power Cable I (6 ft) HDMI Cable (4.9 ft) Optical Audio Adapter (For TVs with optical output) Quick Start Guide & Legal/Warranty Information |
Audio
Amplifiers | All eleven Class-D digital amplifiers have been perfectly tuned to the soundbars' unique acoustic architecture |
Microphones | The far-field microphone array uses advanced beamforming and multi-channel echo cancellation for quick and accurate voice control |
Midwoofers | Eight elliptical woofers ensure faithful playback of mid-range and vocal frequencies plus impressive bass |
Speech Enhancement | Turn this setting on in the Sonos App to boost voice frequencies and clarify dialogue |
Tweeter | Three precisely angled silk-dome tweeters create crisp, high frequencies and crystal clear dialogue |
Adjustable EQ | Use the Sonos App to adjust bass, treble and loudness |
Night Sound | Turn this setting on in the Sonos App to reduce the intensity of loud sounds and increase the level of quieter sounds |
Home Theatre Audio Formats | Stereo PCM, Dolby Digital, Dolby Digital Plus, Dolby Atmos (Dolby Digital Plus), Dolby Atmos*, Dolby TrueHD*, Dolby Atmos (True HD)*, Multichannel PCM*, DTS Digital Surround** (*HDMI eARC connection required. **This is not an indication of a licensed decoder) Sonos App's Now Playing screen will display what type of audio is being decoded |
Details + Dimensions
Colours | Black White |
LEDs | Lights on the product indicate connection, mute status, microphone activation and errors |
Dimensions | 3.4" (87 mm) H x 45" (1142 mm) W x 4.5" (116 mm) D |
Finish | Matte |
Weight | 13.78 lb (6.25 kg) |
Mounting | Thread mount 0.5 in. (12.7 mm) / 10-32 threaded mounting socket |
Controls | Use the capacitive touch controls on the product to adjust the volume, play, pause, skip, and replay, turn off the microphones and more |
Power and Connectivity
WiFi | Connect to WiFi with any 802.11 /b/g/n/ac 2.4 or 5 GHz broadcast-capable router For 5 GHz routers, you can either enable 2.4 GHz 802.11b/g/n in router settings or hardwire a Sonos product |
HDMI eARC | Connect to your TV's HDMI eARC/ARC port with the included HDMI cable If your TV has an optical output only, use the included Sonos Optical Audio Adapter |
Ethernet | 10/100 port for hardwiring to your router |
Voltage | 100-240V 50/60Hz internal power supply |
Infrared Receiver | Syncs the soundbar with your TV remote for streamlined control |
Voice | Works with Amazon Alexa and Google Assistant |
Memory | 1GB SDRAM 4GB NV |
CPU | Quad Core 1.4 GHz A-53 |
Apple AirPlay 2 | Works with AirPlay 2 on Apple devices iOS 11.4 and higher WiFi |
Voice | Works with Amazon Alexa and Google Assistant |
TV Compatibility | Not compatible with CCFL-backlit TVs (manufactured 2004-2012) |
Requirements
WiFi | Internet connection |
Sonos App | The latest generation of the Sonos App running on a compatible device |
Power Source | Nearby electrical outlet |
